Intel D201GLY2 (with integrated Celeron 1.2Ghz CPU) [FANLESS]
PRODUCT IS CURRENTLY NOT AVAILABLE !![Intel D201GLY2 (with integrated Celeron 1.2Ghz CPU) [<b>FANLESS</b>]](https://cartft.com/image_db/Intel_D201GLY2.jpg)
The Intel® Desktop Board D201GLY2 is an innovative solution for the sub-value market segment. With an Intel® Celeron® processor and graphics integrated on the board, this board enables easy system integration and helps you to achieve a lower system cost. This board has 10/100 LAN, support up to six Hi-Speed USB 2.0 ports and 2 SATA (1.5 GB/s), providing both connectivity and ease of use for your computing needs such as email and Internet access, instant messaging and Voice Over IP (VoIP).
The Intel Desktop Board D201GLY2 is built in smaller uATX-Compatible form factor providing lower power consumption and passive thermal solution.
Note
[more]
CPU | Celeron 1.2 Ghz |
Graphics | SiS Mirage |
Formfactor | ITX (17x17cm) |
RAM | 1x DDR-II 400/533/677 |
Audio | AD1888 Codec |
Base | Intel ITX |
USB | 6x USB 2.0 |
Firewire | -- |
IDE/SATA | 1x IDE, 2x SATA |
LAN | 1x 10/100 |
Parallel | 1x |
Serial | 1x |
no | TV-Out |
yes | PCI |
no | Mini-PCI |
yes | IDE |
no | DVI |
no | 800x480 Resolution |
yes | Passive-Cooling |
no | PCI-Express |
no | PCMCIA |
yes | SATA |
no | CPU changeable |
no | Compact Flash |
Compatible enclosures
CFI A-7879 V2 Mini-ITX enclosure (4x 3.5" NAS, 1x 2.5", Hot-Plug, 1x PCI, 250W)
![](https://cartft.com/image_db/CAT_CFI_A-7879.jpg)
M200 Enclosure
![](https://cartft.com/image_db/CAT_M200.jpg)
M200-LCD Enclosure
![](https://cartft.com/image_db/CAT_M200-LCD.jpg)
M350 Mini-ITX enclosure
![](https://cartft.com/image_db/cat_M350.jpg)
MHero-L-B Mini-ITX enclosure (1x PCI, Slimline ODD, 84W PSU)
![](https://cartft.com/image_db/CAT_MHero-B.jpg)
MHero-L-R Mini-ITX enclosure (1x PCI, Slimline ODD, 84W PSU)
![](https://cartft.com/image_db/CAT_MHero-R.jpg)
MHero-S-R Mini-ITX enclosure (with 84W PSU)
![](https://cartft.com/image_db/CAT_MHero-S-R.jpg)
Sehr günstiges und praktisches Board, ich habe die Vorversion mit 1.33Ghz und einem kleinen Lüfter, den ich aber auf Passivkühlung umgemodelt habe.
Inzwischen sind die Atom-Boards aber wohl etwas leistungsfähiger und ich habe mich entschieden, auf ein DG41MJ umzusteigen, da moderne CPUs im Leerlauf (was der Normalfall sein sollte) kaum mehr Strom verbrauchen als spezielle Stromspar-Versionen.
